Guimbal

Manufacturer:

Guimbal

Country:

Europe

Commercial designation:

Cabri

Technical designation:

Cabri

Version, Variant:

G2

Type:

Fenestron

Currently produced:

Y

Typical missions:

Civil VIP School

Flight conditions:

VFR

First flight:

0

Landing system:

skids

Blades number:

3

Tail blades number:

7

MTOW with external loads:

700 kg

1543.5 lbs

MTOW with only internal loading:

700 kg

1543.5 lbs

Empty weight:

420 kg

926.1 lbs

External payload:

0 kg

0 lbs

Internal payload:

280 kg

617.4 lbs

Standard fuel tank:

136 kg

299.88 lbs

with optionnal external fuel tank:

0 kg

0 lbs

Cruise speed:

166 km/h

89.64 kt

Maximum cruise speed:

185 km/h

99.9 kt

Vne:

240 km/h

129.6 kt

Max negative g @ MTOW:

0 g

Max positive g @ MTOW:

0 g

Range with normal tanks:

823 km

444.42 nm

Max range with auxiliary external tanks:

0 km

0 nm

Max endurance @ min consumption speed:

05:40:00 h:min

Rate of climb @ SL:

0 m/s

0 ft/min

Rate of climb @ SL @MTOW:

0 m/s

0 ft/min

IGE max hovering altitude, MTOW:

1500 m

4920 ft

IGE max hovering altitude, empty:

0 m

0 ft

IGE max hovering altitude, ISA+20°C, MTOW:

0 m

0 ft

IGE max hovering altitude, ISA+20°C, empty:

0 m

0 ft

OGE max hovering altitude, MTOW:

0 m

0 ft

OGE max hovering altitude, empty:

0 m

0 ft

OGE max hovering altitude, ISA+20°C, MTOW:

0 m

0 ft

OGE max hovering altitude, ISA+20°C, empty:

0 m

0 ft

Service ceiling ISA, MTOW:

0 m

0 ft

Max operating altitude, empty weight:

0 m

0 ft

Highest use Temperature:

0 °C

0 °F

Lowest use Temperature:

0 °C

0 °F

APU in HC:

N

Engine manufacturer:

Textron Lycoming

Model:

O360-J2A

Engines quantity:

1

Powerplant category:

piston

Main rotor rotation speed:

530 rpm

Fuel consumption @ SL @ max continuous speed:

0 kg/kW/h

0 lbs/hp/h

Minimum consumption speed @ SL:

0 km/h

0 kt

Fuel consumption @ eco cruise speed @SL:

0 kg/h

0 lbs/h

Fuel consumption @ min consumption speed @ SL:

0 kg/h

0 lbs/h

Engines nominal power:

108 kW

146.772 hp

Transmission shaft max continuous power:

0 kW

0 hp

Transmission shaft max power:

0 kW

0 hp

Takeoff power 5 min:

0 kW

0 hp

OEI 30s power:

0 kW

0 hp

OEI 2min power:

0 kW

0 hp

OEI max continuous power :

0 kW

0 hp

OEI max continuous transmission power:

0 kW

0 hp

OEI 30 sec transmission power:

0 kW

0 hp

OEI 2 min transmission power:

0 kW

0 hp

Overall length:

8.05 m

26.404 ft

Rotor diameter:

7.2 m

23.616 ft

Tail rotor diameter:

0.6 m

1.968 ft

Fuselage length:

6.31 m

20.6968 ft

Overall height:

2.37 m

7.7736 ft

Main rotor blades chord:

0.18 m

0.5904 ft

Tail rotor blades chord:

0.042 m

0.13776 ft

Mast tilt angle:

0 °

Noise at flyover, level:

75.7 dB EPNL

Noise at flyover, limit:

82 dB EPNL

Noise at takeoff, level:

0 dB EPNL

Noise at takeoff, limit:

0 dB EPNL

Noise at landing, level:

0 dB EPNL

Noise at landing, limit:

0 dB EPNL

Crew:

1

Max pax number:

1

Average price:

250000 $
